FLOWPACK

X3 is the most compact flow-pack machine model in the range. It is a genuine concentration of technology derived from our top-of-the-range models in a smaller format. This allows it to stand out in terms of quality and performance compared to the alternatives on the market in the entry-level machine segment.

Due to its characteristics, the X3 is an ideal solution for small but very varied production runs.

Its compact size lends itself well to situations where space is limited.

Moreover, this model is highly customizable, like the rest of our range.

Therefore, flexibility, compactness, and adaptability are the primary and essential advantages this model can offer its user.

The X-3 works well with various packaging materials, including recyclables, biodegradable, compostable, and paper films, that the market demands with a view to environmental sustainability.

features

Servo motor on head for precise and independent movement of the head
Removable pushers, for quick replacement and/or format change.
Storable bag length andpusher head-cutter phase for quick and easy format changeovers.
Speed can be stored in each recipe, for easy format changeover.
Stop in phase, avoids overheating of the film in case of prolonged stop, preserving the sealsImmediate jaw retraction in case of jamming, facilitates product evacuation and preserves the head mechanics.
Jaw release with push button, for precise and efficient resetting in the event of entrapment.
Universal forming tunnel, to adapt to any format, allowing the width and height of the bag to be adjusted on demand.
Self-centring reel holder, regardless of the reel width used, the film is always centred without the need for any adjustment.
Progressive reel brake, as the film reel is consumed, the brake is automatically changed so that the operator does not have to worry about it.
Control panel with colour touch screen, allows quick format changeover and intuitive management of all the machine parameterisation options.
Real-time diagnostics, displaying the machine’s operating status on the screen, to quickly locate any anomalies.
Three pairs of sealing wheels guarantee a better result in longitudinal bag welding.
Instantaneous speed reducer, to facilitate machine operation in situations that require lower packaging speed and optimise times.
Storable temperatures for each recipe, to facilitate and make format changeover even faster.
Preventive maintenance warnings, to warn of the appropriate time for a check-up

options

The X-3 can be customised with multiple accessories to increase efficiency based on customer needs and/or product requirements.

Some of the accessories are:

Photo-eye system for registered film, allowing the use of films printed with marks to centre the design on the product.
No product No bag, avoids producing empty bags by putting the machine waiting for the conveyor to deliver the product, with immediate restart when available..
Stop no product, temporarily stops the machine when product has not been loaded on the in-feed conveyor
Accompanying rollers in the head-cutter make it easier to pass the product through the sealing jaws, avoiding jolts and possible product spillage.
Stop no film, stops the machine automatically in case the film reel runs out.
Printers/Markers, to print information such as batch number, production/expiration date or barcodes and images directly on the film in real time.
Labellers, toapply or print labels on the finished pack or directly on the film before forming.
Rotary table, placed at the exit of the flow-pack, receives the products already packaged to facilitate successive packaging operations.
Automatic loaders, customised for every circumstance and need.

SPEED CYCLES/MINUTE:	80 cycles/min.	Multi-axle transmission
DIMENSIONS OF PRODUCTS: LENGHT: WIDTH: HEIGHT:	80-350mm. 10-220mm. 10-120mm.	storable Universal tunnel.
FILMS REEL SIZES:	Max. 550mm.	Internal diameter 60-110mm. Max external diameter 350mm. Max. Weight 35kg
MACHINE WEIGHT:	400kg
PACKAGING MATERIAL:	Bi-oriented polypropylene (BOPP), biodegradable and compostable polylactic acid polyester (PLA), fully breathable paper, transparent cellulose and various multilayer complexes.
ELECTRICAL INSTALLATION:	Single phase 220V. 50/60hZ. Max. consumption: 2,5Kw.
COLOUR AND TREATMENTS:	Grey colour with blue details. Epoxy type oven painted with long durability and totally compatible with foodstuffs. The metal treatments are high resistance electrolytes.
