VR8 MASTER

FLOWPACK

The VR8 Master is a flow-pack machine model combining flexibility, performance, and reliability.

It can handle heavy workloads in a wide range of applications.

The sealing unit’s dimensions and reel support allow for packing an extensive range of product sizes. It is suitable for both tray and trayless product packaging.

It is an ideal solution for medium-high production.

The VR8 Master works well with various packaging materials, including recyclables, biodegradable, compostable, and paper films, which the market demands for environmental sustainability.

features

  • Accompanying rollers in the head-cutter  make it easier to pass the product through the sealing jaws, avoiding jolts and possible product spillage.
  • Sealing jaw width of 350mm, allowing for greater format capacity.
  • Removable pushersfor quick replacement and/or format change.
  • Storable bag length andpusher head-cutter  phase for quick and easy format changeovers.
  • Speed can be memorised in each recipe, for easy format changeover.
  • Stop in phase, avoids overheating of the film and the consequent possible deterioration of the seals in the event of a prolonged temporary stop.
  • Immediate retraction of the jaws in the event of entrapment, facilitates product evacuation and preserves the mechanics of the head.
  • Jaw release with push button, for precise and efficient resetting in the event of entrapment.
  • Universal film forming tunnel, to adapt to any format, allowing the width and height of the bag to be adjusted on demand.
  • Self-centring reel holder, regardless of the reel width used, the film is always centred without the need for any adjustment.
  • Progressive reel brake, as the film reel is consumed, the brake is automatically changed so that the operator does not have to worry about it.
  • Control panel with colour touch screen, allows quick format changeover and intuitive management of all the machine parameterisation options.
  • Real-time diagnostics, displaying the machine’s operating status on the screen, to quickly locate any anomalies.
  • Three pairs of sealing wheels guarantee a better result in the longitudinal welding of the bag.120mm wheel diameter to guarantee perfect sealing.
  • Instantaneous speed reducer, to facilitate the operation of the machine in situations that require lowering the packaging speed and optimising times.
  • Memorable temperatures for each recipe, to facilitate and make the format change even faster.
  • Preventive maintenance warnings, to warn of the appropriate time for an overhaul.

options

The VR-8 Master can be customised with multiple accessories to increase efficiency based on customer needs and/or product requirements.

Some of the accessories are:

  • Photo-eye system for registered film, allowing the use of films printed with marks to centre the design on the product.
  • Second reel holder, for easy availability of a reel of the same size or of a different format, speeding up replacement.
  • Automatic reel changeover, allowing work to continue without interruption due to the termination of a film reel, achieving maximum efficiency.
  • Stop no product, temporarily stops the machine when product has not been loaded on the in-feed conveyor
  • Accompanying brushes system , to accompany the product and ensure its stability during the packaging phase.
  • Stop no Film , stops the machine automatically if the film reel runs out.
  • Extension of the infeed conveyor to provide more space in the loading area to accommodate more operators and thus achieve a higher speed.
  • Printers/Markers, to print information such as batch number, production/expiration date or barcodes and images directly onto the film in real time.
  • Labellers, to print or apply labels on the finished pack or directly on the film before forming.
  • Rotary table, positioned at the exit of the flow-wrapper, receives the products already packed to facilitate successive packaging operations.
  • Inverse version, with product loading from left to right to adapt to the available space or to integrated production lines.
  • Automatic loaders, customised for every circumstance and need.
SPEED METRES/MINUTE: 20 mt/min.,(80 cycles/min.) Multi-axle transmission
DIMENSIONS OF PRODUCTS:

LENGHT:

WIDTH:

HEIGHT:



120-450mm.

10-280mm.

10-120mm.



Storable

Universal tunnel.



FILMS REEL SIZES: Max. 800mm.



Internal diameter 70mm.

Max external diameter 350mm.

Max. Weight 35kg

MACHINE WEIGHT: 800kg
PACKAGING MATERIAL: Bi-oriented polypropylene (BOPP), biodegradable and compostable polylactic acid polyester (PLA), fully breathable paper, transparent cellulose and various multilayer complexes.
ELECTRICAL DATA: Single phase 220V. 50/60hZ.

Max. consumption: 2,5Kw.



COLOUR AND TREATMENTS: Metallic grey colour. Epoxy type oven painted with long durability and totally compatible with foodstuffs. The metal treatments are high resistance electrolytes.
